The T Series is a compact, reliable reach mower designed for ranchers, farmers, hobby farmers, landscape contractors and municipalities. The reliability and strength are ensured by the new Delta Box frame. Compact and powerful, the pump engaging the rotor is entirely made of cast iron.
Max horizontal reach: 8’3” Tractor power: 20 - 35 HP Min. tractor weight: 1543 lbs Min. tractor width: 3’3” Weight: 749 lbs Rotor power: 20 HP Power of hydraulic system: 31 HP Flail head angle: 190° Max Cutting width: 3/4"
Max horizontal reach: 10’7” Tractor power: 25 - 40 HP Min. tractor weight: 1984 lbs Min. tractor width: 3’11” Weight: 816 lbs Rotor power: 20 HP Power of hydraulic system: 31 HP Flail head angle: 190° Max Cutting width: 3/4"
Max horizontal reach: 15'1" Tractor power: 50 - 60 HP Min. tractor weight 4850 lbs Min. tractor width 5'11" Weight 1279 lbs Rotor power 35 HP Power of hydraulic system 45 HP Flail head angle 190° Max Cutting width 1 1/4"
Max horizontal reach: 12'7" Tractor power: 40 - 60 HP Min. tractor weight: 3747 lbs Min. tractor width: 4'11" Weight: 1080 lbs Rotor power: 20 HP Power of hydraulic system: 31HP Flail head angle: 190° Max Cutting width: 1 1/4"
Max horizontal reach: 14'2" Tractor power: 50 - 70 HP Min. tractor weight: 4409 lbs Min. tractor width: 5'6" Weight: 1091 lbs Rotor power: 20 HP Power of hydraulic system: 31 HP Flail head angle: 190° Max Cutting width:1 1/4"
Automatic roll-over protection when the first arm exceeds 90° in vertical position.
“DELTA BOX” FRAME
In consideration of the stress the reach mowers are subjected to during work, Ferri developed a new concept of frame, called «DELTA BOX» made of two sheet walls, which are laser-cut and joined with formed steel. The whole is welded on a robotized system; the structural design achieved is extremely light weight and strong.
Reliability and simply use. Standard on all machines Classic.
ELECTRA FULL - PROGRESSIVE ELECTRICAL CONTROL WITH ELECTRICAL ROTOR MANAGEMENT
Both distributors are actuated by means of a mixed system. The joystick controls the function of the first and second booms, while the head tilting and rotor movement are electrically controlled via the buttons above the joystick. The rotor drive is electrically controlled by the switch.
