Stock #  706

Teagle Tomahawk 8100

Videos
Call for Price
Overview

Tomahawk 8100

Our most popular bale processor on the market.

Our experience and attention to detail delivers outstanding reliability & performance from the UK's most popular bale processor.

  • Straw is lightly shredded improving moisture absorbance and livestock comfort, as the straw is not chopped the bed retains it's structure and provides an hygienic environment.

Increase consumption and reduce waste of baled silage.

  • Silage that is lightly shredded with a Tomahawk 8100 is more palatable and easily consumed.
  • 96 bushels capacity, for feeding baled and clamp silage.
  • Spreads straw up to 72' from rectangular or round bales.
  • Also available with Side Chute, Twin Chutes or in ‘Dual Chop format’, for long or short straw at the touch of a button.

Outstanding 'Flow Plus' Performance to save you money.

  • Greater output
  • More consistent feed rate
  • Controlled delivery at low fan speeds



Specifications
Model
Tomahawk 8100
Year
2021
Sale Type
New
Manufacturer
Teagle
benefits and features
Teagle Tomahawk 8100

Easy Tailgate Loading

Tailgate is flared for easy loading and is supported by two hydraulic rams to enable the heaviest of bales to be loaded.
Teagle Tomahawk 8100

Heavy Duty Bed Chain

12mm heavy duty bed chain, resulting in less tensioning adjustments. The chain does not have anything welded to it, which would lower its strength.
Teagle Tomahawk 8100

Swivel Chute
For flexibility of delivery, the chute rotates 280? allowing material to be directed to where it is needed. An adjustable feed slide is fitted for accurate placement of feed materials.

Teagle Tomahawk 8100

Wireless Control

Slimline control panel uses Bluetooth® wireless technology for straight-forward communication between the operator and the Telehawk.
Teagle Tomahawk 8100

High Performance Valve

Hydraulic valve can take up to 60 litres/minute, resulting in less heating of the oil, faster response to the controls and more power being delivered to the Tomahawk.
Teagle Tomahawk 8100

Slip and overrun on PTO

For driveline protection a slip clutch is fitted as standard on the Walterscheid PTO shaft.
Teagle Tomahawk 8100

Robust Transmission

Chain drive to crossbeater ensures reliable transmission of maximum power.
Teagle Tomahawk 8100

Consistent Output

The bale restraint design works with the grippers on the slats to give a good tumbling action, ensuring a consistently high discharge rate with all materials.
Teagle Tomahawk 8100

Tailgate Mechanism and Under Floor Panel

The Rear Door has two hydraulic cylinders to reduce stress on the chassis. The Tomahawk has an underfloor panel fitted; useful for maintenance.

Teagle Tomahawk 8100 Adjustable Feed Slide
For accurate placement of feed materials.

Teagle Tomahawk 8100 Large Diameter Crossbeater
The crossbeater has 400mm diameter barrel, 600mm from blade tip to blade tip. Large diameter means more consistent flow and power requirement.

product specifications
  8100
Capacity (Cubic feet) 120
Chute Side
Dual Chop
No
Straw Spread
No. of crossbeaters 1
Capacity (bushels) 96
No. of 5' round bales 2
No. of 8' rectangular bales (4'x3' / 4'x4') 1/1
Bale chamber (tailgate down) W x H x D 5'1" x 4'1" x 9'9"
Blow distance (max.) 72'
Min. tractor PTO 60HP
Overall width (chute closed) 7'5"
Overall length (tailgate up) 13'7"
Overall length (tailgate down) 17'8"
Overall height (chute closed) 7'11"
Unladen weight 4,145 lb
Tyre size 10.00/75-15.3 (options available)
Oil flow rate (min/max) US gallons/min 9.3 - 15.9
Feed Baled Silage Yes
Feed Clamp Silage Yes
Bed Cubicles / Straw Processing No
Bed Loose Housing Yes
Teagle Tomahawk 8100
additional options

8100 Side Discharge Chute Teagle Tomahawk 8100
Deliver only to the right hand side, with slightly greater blow distance than the swivel chute. Discharge height is lower for easier access to buildings. Chute can be raised or lowered as required.

Teagle Tomahawk 8100 Road Lighting Kit
Essential for highway use, the front and rear markers ensure that you operate safely when travelling on the road.

Teagle Tomahawk 8100 Tailgate Extension
Essential for highway use, the front and rear markers ensure that you operate safely when travelling on the road.

Teagle Tomahawk 8100 Hydraulic Filter
In-line high pressure filter stops contamination from damaging the valve equipment.

Teagle Tomahawk 8100

Consistent Output

The bale restraint design works with the grippers on the slats to give a good tumbling action, ensuring a consistently high discharge rate with all materials.

Teagle Tomahawk 8100 Greedy Boards
Increase capacity for loose materials. Available only for 8150/8550 models.

Teagle Tomahawk 8100 Pig Arc Chute
A chute extension designed specifically for bedding pig arcs. Straw is easily directed through the front of the arc and into the bedding area. Note - this option can only be fitted to side chute models.

Teagle Tomahawk 8100 Wide Angle PTO
For continuous operation when turning corners a Wide Angle Walterscheid PTO shaft is also available.

Teagle Tomahawk 8100 Clevis Drawbar and Jack
Where no pick up hitch is available a clevis drawbar and jack is available for straight forward hitching and unhitching.



literature
Name Link
Tomahawk Bale Processor Brochure Download
Product Guide Download
